1.5 Marking of safety references contained in these instructions
Note Refers to tips and other particularly helpful information.
Caution Refers to particular methods of operation or handling, non-adherence to which can lead to mal-
functioning, damage or other problems.
Danger Refers to dangerous situations which can lead to injuries.
2 Starting up
2.1 Technical data
Machine designation : Automatic blasting unit
Machine type : D-G 16 S2
Unit dimensions : Width 480 mm (with plug for pedal switch),,
Depth 570 mm,
Height 705 mm
Electrical connection : 230 Volt/50 Hz
Overvoltage category : II
Power consumption : max. 460 Watts
Sound pressure level : 58 dB(A) min. air capacity
68 dB(A) max. air capacity
Fine-particle filter quality: : dust class M, DIN EN 60335
Electrical fusing : 2x 5 A/T
Compressed air connection : max. 10 bar
Compressed air consumption : approx. 200 l/min. (per injector)
approx. 400 l/min (with simultaneous operation)
Blasting chamber illumination : E 14 230V / 40 watt incandescent lamp
Weight : Approx. 38 kg
2.2 Unpacking the automatic blasting unit
1. Remove upper crate cover.
Note Position the crate on two squared timbers or a pallet to facilitate removal of the two M8 pack
ing
screws on the underside of the crate.
2. Unscrew 2x M8 packing screws.
3. The unit must be lifted out of the crate by two people (approx. 38 kg).
4. Check the accessories:
- Documentation
- Mains power supply connection cable ................................................................... No. 35028
- Pedal switch with cable and plug ........................................................................... No. 67010
- 2 m PVC fabric hose, blue, Ø 8.2 x 6
with plug-in socket for rapid action coupling and coupling ring .............................. No. 72350
- See delivery docket for any possible further accessories
