D-G 16 S2 - 18.04.13 / Vers.: 1
7
2.4 Process for putting into operation
(see fig. 2 page 5)
1. Connect unit to compressed air supply (see section “3.1”).
2. Fill blasting agent (see section “3.2”).
3. Check filter system (see section “3.3“).
4. Connect pedal switch to plug socket (1) (in blasting chamber during transportation)
5. Insert mains connection plug (in blasting chamber during transportation) in plug socket (15) and
establish connection to mains supply (230 V/50 Hz).
6. Automatic operating mode (see section “3.4”).
7. Manual blasting (see section “3.6”).
3 Operation
3.1 Connect sandblasting device to the compressed air supply
(see fig. 2 page 5)
1. Connect fabric hose included in delivery to compressed air connection (16).
2. Connect plug-in socket for rapid action coupling with compressed air supply (max. 10 bar).
Caution
Only compressed air free of moisture and oil should be used.
A water separator should be installed directly prior to, or at a max. of 1 m distant from,
to ensure fault-free operation.
3.2 Filling with blasting agent
(see diag. 1 & 2 page 4 & 5)
The unit is designed by the manufacturer to be used with the following blasting agents:
Type of blasting agent Blasting agent category
Special fused alumina (aluminium oxide) EW 60 (250 µm)
EW 80 (180 µm)
Cat. 60 B (120 µm)
Polishing blasting agent Cat. 150 A (150 µm)
Caution
The unit is designed for use with Harnisch+Rieth blasting agents. Harnisch+Rieth are not liable
for any malfunction or damage resulting from the use of other blasting agents.
1. Open front flap (2)
Note Unscrew knurled nut for shove-in sieve (10) and pull out shove-in sieve (8) to about
3
/
4
length to facilitate inspection of the blasting agent filling level.
2. Fill blasting agent to about 4 cm under the height of the shove-in sieve (8).
Caution
It should be ensured that there are no dirt particles in the blasting agent to avoid malfunctions.
3. Shove in sieve (8) and tighten knurled nut(10) lightly.
