HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 1
Chapter 1
Introduction
Overview
The HMX6801+B2/C2 and HMX6801+B4/C4 are two-channel and
four-channel HD or SD audio multiplexers, respectively. The
HMX6801+B2 and HMX6801+C2 modules can embed two AES audio
signals into two groups within the SDI output signal, while the
HMX6801+B4 and HMX6801+C4 can embed four AES audio signals
into two groups. “B2/B4” versions of the modules embed balanced
signals, while “C2/C4” versions embed unbalanced signals.
The following topics are described in this chapter:
• “Product Description” on page 2
• “Module Descriptions” on page 4
• “Signal Flow” on page 10
