HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 65
Chapter 4
Specifications
Overview
The following specification tables appear in this chapter:
• “SDI Video Input” on page 66
• “AES Balanced Input (HMX6801+B2/B4 Only)” on page 67
• “AES Unbalanced Input (HMX6801+C2/C4 Only)” on page 67
• “DARS Input (HMX6801+B2/C2 Only)” on page 68
• “SDI Video Output” on page 69
• “AES Balanced Output (HMX6801+B2 Only)” on page 70
• “AES Unbalanced Output (HMX6801+C2 Only)” on page 70
• “Propagation Delay” on page 71
• “Power Consumption” on page 71
• “Operating Temperature” on page 71
Specifications and designs are subject to change without notice.
