HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 71
Chapter 4: Specifications
Propagation Delay
Power Consumption
The total power consumption for the HMX6801+B2/C2 and
HMX6801+B4/C4 is approximately 7 W from the positive supply and
0.2 W from the negative supply.
Operating Temperature
The operating temperature for HMX6801+B2/C2 and
HMX6801+B4/C4 modules is 41° to 113°F (5° to 45°C).
Note
Applicable to combinations of
HMX6801+ and HDX6801+
modules
Table 4-8. Propagation Delay Specifications
Item Specification
Video HD mode < 1us
SD mode < 2.2us
Audio
(typical with minimum delay
setting; combined embedding
and de-embedding)
HD mode
• PCM mode: 5.5 ms
• Non-PCM mode: 2.55 ms
SD mode
• PCM mode: 4.4 ms
• Non-PCM mode: 1.38 ms
