12 HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual
Chapter 2: Installation
Maximum 6800+ Frame Power Ratings
The power consumption for HMX6801+B2/C2 and HMX6801+B4/C4
modules is 7 W from the positive supply and 0.2 W from the negative
supply. Power consumption information is also listed in the
Specifications chapter.
Table 2-1 states the maximum allowable power ratings for 6800+
frames. Note the given maximums before installing any 6800+ modules
in your frame. HMX6801+ modules cannot be installed in frames
without fans, or in FR6802+DM and 6800/7000 series frames.
Table 2-1. Maximum Power Settings for 6800+ Frames
6800+ Frame Type
Max. Frame
Power
Dissipation
Max.
number of
Installed
HMX6801+
Modules
Max Power
Dissipation
for Two
Slots
FR6802+QXF
(frame with AC or DC
power supply)
120 W 10 12 W
FR6802+XF
(frame with AC power
supply)
120 W 10 12 W
FR6802+XF
(frame with DC power
supply)
120 W 10 10.5 W
