38 HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual
Chapter 3: Operation
Changing Parameter Settings
Follow these steps to change the HMX6801+B2/C2 and
HMX6801+B4/C4 parameter settings:
1. Rotate the mode select rotary switch (hex switch) to “0.”
2. Once the hex switch is set to “0,” toggle the navigation switch up or
down to select a bank.
View the three control LEDs next to the navigation toggle switch to
see which bank is currently selected.
See Table 3-9 on page 41 to view the various banks, hex switch
positions, and corresponding parameter options and values.
3. Rotate the hex switch to the parameter number (1 to 9) or letter
(A to F) of the option you want to set.
4. Toggle the navigation switch to select and set the value of the
chosen parameter.
5. Rotate the hex switch to another parameter number/letter in the
current bank, and then repeat step 4.
or
Rotate the hex switch to “0” again to select a different bank, and
then repeat steps 3 and 4.
Table 3-8. Selected Bank as Indicated by Control LEDs
Bank Select LED 1
(first top LED)
Bank Select LED 2
(second top LED)
Bank Select LED 3
(third top LED)
Bank Number
Off Off Off 0
On Off Off 1
Off On Off 2
On On Off 3
Off Off On 4
On Off On 5
OffOnOn6
On On On 7
The manufacturer recommends
that you use the available 6800+
software control options
(serial/local or Ethernet/remote)
to aid in viewing, setting, and
confirming parameter values.
