HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 5
Chapter 1: Introduction
Table 1-1. Generic 6800+ Module Features
Feature Description
Module status
LEDs
Various color and lighting combinations of these LEDs
indicate the module state. See “Monitoring LEDs” on
page 61 for more information.
Mode select
rotary switch
This switch selects between various control and
feedback parameters.
Navigation
toggle switch
This switch navigates up and down through the available
control parameters:
• Down: Moves down through the parameters
• Up: Moves up through the parameters
Control LEDs Various lighting combinations of these Control LEDs
(sometimes referred to as “Bank Select LEDs”) indicate
the currently selected bank. See Table 3-8 "Selected
Bank as Indicated by Control LEDs"for more
information.
Monitoring
LEDs
Each 6800+ module has a number of LEDs assigned to
indicate varying states/functions. See “Monitoring
LEDs” on page 61 for a description of these LEDs.
Local/remote
control jumper
• Local: Locks out external control panels and allows
card-edge control only; limits the functionality of
remote software applications to monitoring
• Remote: Allows remote or local (card-edge)
configuration, operation, and monitoring of the
HMX6801+B2/C2 and HMX6801+B4/C4
