HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 25
Chapter 3: Operation
Append Embedding
Figure 3-1. Append Embedding Mode, Part 1
EAV
ADS before embedding
EAV
ADS after embedding group
Group 1
ADS before embedding
Other
auxilliary data
A
EAV
Other
auxilliary data
B
ADS after embedding group
Group 1
EAV
Other
auxilliary data
A
Other
auxilliary data
B
ADS before embedding
Pre-existing
Group 1
EAV
EAV
Pre-existing
Group 1
Result: Error is returned
