HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 27
Chapter 3: Operation
Overwrite Embedding
Figure 3-3. OverWrt Embedding Mode
ADS before embedding
EAV
EAV
ADS before embedding
other
auxilliary data
A
other
auxilliary data
B
ADS after embedding group 1 (with overwrite group specified as Group 1)
Group 1
EAV
ADS before embedding
Pre-existing Group 1
EAV
ADS after attempting to embed group 1
EAV
other
auxilliary data
A
other
auxilliary data
B
Result: Error is returned
EAV
ADS after attempting to embed group 1
Result: Error is returned
