34 HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual
Chapter 3: Operation
Output Ch04 Format = PCM
or
Output Ch04 Format = Auto and
Out Ch04 Format Fb = PCM
• Output Ch04 Gain = Enabled
• Output Ch04 Invert = Enabled
Output Ch05 Format = Non-PCM
or
Output Ch05 Format = Auto and
Out Ch05 Format Fb = Non-PCM
• Output Ch05 Gain = 0 dB
• Output Ch05 Invert = No
• Output Ch05 Gain = Disabled
• Output Ch05 Invert = Disabled
Output Ch05 Format = PCM
or
Output Ch05 Format = Auto and
Out Ch05 Format Fb = PCM
• Output Ch05 Gain = Enabled
• Output Ch05 Invert = Enabled
Output Ch06 Format = Non-PCM
or
Output Ch06 Format = Auto and
Out Ch06 Format Fb = Non-PCM
• Output Ch06 Gain = 0 dB
• Output Ch06 Invert = No
• Output Ch06 Gain = Disabled
• Output Ch06 Invert = Disabled
Output Ch06 Format = PCM
or
Output Ch06 Format = Auto and
Out Ch06 Format Fb = PCM
• Output Ch06 Gain = Enabled
• Output Ch06 Invert = Enabled
Output Ch07 Format = Non-PCM
or
Output Ch07 Format = Auto and
Out Ch07 Format Fb = Non-PCM
• Output Ch07 Gain = 0 dB
• Output Ch07 Invert = No
• Output Ch07 Gain = Disabled
• Output Ch07 Invert = Disabled
Output Ch07 Format = PCM
or
Output Ch07 Format = Auto and
Out Ch07 Format Fb = PCM
• Output Ch07 Gain = Enabled
• Output Ch07 Invert = Enabled
Output Ch08 Format = Non-PCM
or
Output Ch08 Format = Auto and
Out Ch08 Format Fb = Non-PCM
• Output Ch08 Gain = 0 dB
• Output Ch08 Invert = No
• Output Ch08 Gain = Disabled
• Output Ch08 Invert = Disabled
Output Ch08 Format = PCM
or
Output Ch08 Format = Auto and
Out Ch08 Format Fb = PCM
• Output Ch08 Gain = Enabled
• Output Ch08 Invert = Enabled
Table 3-5. Cross-Functional Parameters (Continued)
Condition Forced Setting Enabled/Disabled Parameters
