HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual 45
Chapter 3: Operation
1, 7 Out 07 Source
Select
Selects the source for output
channel 07
• AES 1A
• AES 1B
• AES 2A
• AES 2B
•AES 1 Sum
•AES 2 Sum
• TstTone 1
• TstTone 2
• TstTone 3
•TstTone 4
1, 8 Out 08 Source
Select
Selects the source for output
channel 08
• AES 1A
• AES 1B
• AES 2A
• AES 2B
•AES 1 Sum
•AES 2 Sum
• TstTone 1
• TstTone 2
• TstTone 3
•TstTone 4
1, 9 AES Out 1
Source Sel
Selects the source for AES output 1
• Emb1 Pair1
•Emb1 Pair2
•Emb2 Pair1
•Emb2 Pair2
1, A AES Out 2
Source Sel
Selects the source for AES output 2
•Emb1 Pair1
• Emb1 Pair2
•Emb2 Pair1
•Emb2 Pair2
1, B to
2, 3
Output Ch01
Format
to
Output Ch08
Format
Selects the AES format for output
channels 01 to 08
•PCM
•Non-PCM
2
• Auto
