0, 2 Y CRC Err Cnt
Clear
Clears the luminance CRC error
counter
• No
•Yes
0, 3 C CRC Err Cnt
Clear
Clears the chrominance CRC error
counter
• No
•Yes
0, 4 EDH Err Clr Clears the EDH error counter
• No
•Yes
0, 5 ADS Clean Cleans the Ancillary Data Space
prior to audio embedding
• No
•Yes
0, 6 Embedder Group
Select
1
Selects the audio groups to be
embedded
• 1 & 2
•1 & 3
•1 & 4
•2 & 3
•2 & 4
•3 & 4
0, 7 Embedder 1
Mode
Selects the embedding mode for the
first embedder
•Off
• Append
• OverWrt
• Auto
0, 8 Embedder 2
Mode
Selects the embedding mode for the
second embedder
•Off
• Append
• OverWrt
• Auto
0, 9 Input Ch1A
Delay
Adjusts delay for input channel
AES 1A
0.0 to 1320.0 msec
0, A Input Ch1B Delay Adjusts delay for input channel
AES 1B
0.0 to 1320.0 msec
0, B Input Ch2A
Delay
Adjusts delay for input channel
AES 2A
0.0 to 1320.0 msec
0, C Input Ch2B Delay Adjusts delay for input channel
AES 2B
0.0 to 1320.0 msec
Table 3-11. Parameter Options - HMX6801+B4/C4 (Continued)
Bank, Rotary
Switch
Parameter
Name
Function Options
