60 HMX6801+B2/C2 and HMX6801+B4/C4 Installation and Operation Manual
Chapter 3: Operation
[RO] Input Ch3B Vbit Fb Reports the validity bit status of input
channel 3B
•Off
•On
[RO] Input Ch4A Vbit Fb Reports the validity bit status of input
channel 4A
•Off
•On
[RO] Input Ch4B Vbit Fb Reports the validity bit status of input
channel 4B
•Off
•On
[RO] Out Ch01 Format Fb
to
Out Ch08 Format Fb
Reports the AES format of output
channels 01 to 08
•PCM
• Non-PCM
[RO] Output 01 Status
to
Output 08 Status
Reports the status (peak/silence/normal)
of output channels 01 to 08
• Peak
• Silence
• Normal
1 Parameters designated as read-only [RO] are only available from a remote CCS software control ap-
plication such as Pilot or Navigator
Table 3-12. HMX6801+B2/C2 Read-Only Parameters—Remote Control Only (Continued)
Bank,
Rotary
Switch
Parameter Name Function Options
