Harris NetWave User Manual

Revision A • 6/06
HARRIS CORPORATION
1-9
1 Introducing NetWave
Digital Inputs and Outputs (cont.)
Processing Resolution: 24-bit fixed with extended
precision accumulators
Conversions:
A/D: 24-bit, Delta-Sigma, 128x over-
sampling on all digital inputs; D/A: 24-bit,
Delta-Sigma, 128x oversampling
Latency:
<600µs, any input to monitor output
Monitor Outputs
Output Source Impedance: <3 ohms, active balanced
Output Load Impedance: 1 k ohms min.
Output Level: +4 dBu nominal, +24 dBu max.
Frequency Response
Input to Program Output: +0.3 dB/-0.1 dB, from
20 Hz to 20 kHz
Dynamic Range
Analog Input to Analog Output: 106 dB referenced to
FSD, 108 dB “A” weighted to FSD
Analog Input to Digital Output: 108 dB referenced to
FSD, 110 dB “A” weighted to FSD
Digital Input to Analog Output: 108 dB referenced to
FSD, 111 dB “A” weighted to FSD
Digital Input to Digital Output: 115 dB
Total Harmonic Distortion + Noise
Analog Input to Analog Output: <0.003%, 20 Hz to
20 kHz (<0.002% typical at 1k), +18 dBu in-
put, +18 dBu output
Analog Input to Digital Output:
<0.0009%, 20 Hz to
20 kHz,+18 dBu input, -6 dB FSD output
Digital Input to Analog Output:
<0.003%, 20 Hz to
20 kHz (<0.002%, typical at 1 kHz), -6 dB FSD
input, +18 dBu output
Digital Input to Digital Output:
<0.0005%, 20 Hz to
20 kHz, -6 dB FSD input, -6 dB FSD output
Crosstalk Isolation
Program-to-Program : -85 dB, 20 Hz to 20 kHz
Stereo Separation
Analog Program Outputs: >90 dB, 20 Hz to 20 kHz
Console Power Requirements
Measured at 120 VAC/60 Hz.
NetWave-8: 54 watts
NetWave-16: 99 watts
NetWave-24
: 141 watts
Required Supply Voltage
NetWave-8: +48 VDC @ 1.2 amps
NetWave-16: +48 VDC @ 2 amps
NetWave-24
: +48 VDC @ 3 amps
One power supply included. The NetWave-8 and
NetWave-16 use a 50-27 supply. The NetWave-
24 uses a 99-1205 supply.
An optional Power Coupler (90-1995) is avail-
able for adding a matching redundant supply
for on-air consoles.
Power Supply Ground
Rack mount or in-line power supply: grounded through
the AC input cord ground pin
Power Supplies
AC input voltage & frequency: 90-240 VAC, 50/60 Hz
AC input: detachable IEC power cord
DC output: Uses a keyed, latching connector on a
captive cable on the 50-27 supply or a detach-
able cable (90-1858-1) on the 99-1205 supply
Dimensions
All NetWave consoles: 3" [76] max height above coun-
tertop, except for console reflector, 6" [152].
Front-to-back depth is 21" [533].
NetWave-8 is 20" [508] wide
NetWave-16 is 32.4" [823] wide
NetWave-24 is 45.2" [1148] wide
50-27 (in-line supply for NetWave-8 and NetWave-16):
2" [51] x 3.8" [97] x 9.5" [241]
99-1205 (rack mount supply for NetWave-24):
2 RU: 3.5" [89] x 19" [483] x 10" [254]
All dimensions: Height x Width x Depth.
Harris Corporation reserves the right to change
specifications without notice or obligation
