Revision A • 6/06
HARRIS CORPORATION
5-2
5 Service
SPARE AND REPLACEMENT PARTS
Main component locations are shown on page 5-8
Serviceable Assemblies
Harris # Description or Use
90-1990-08 Console Display Assembly, NetWave-8
90-1990-16 Console Display Assembly, NetWave-16
90-1990-24 Console Display Assembly, NetWave-24
90-2129 Dual Stereo Bargraph Meter PCA
90-2130 Clock & Event Timer PCA
99-1205 48 Volt Power Supply (2 RU)
99-1420 DSP & I/O card
99-1421 Monitor & Output card
99-1422 Monitor Panel
99-1423 Dual Fader Panel
Replacement Parts
Harris # Description or Use
12-93 10-character display
17-122 Headphone jack
19-64 Flex Cable, 50-conductor
19-338 12" Red CAT-5 cable (panel power & comm.)
21-226-10 PROM, Monitor panel
21-226-11 PROM, Dual Fader panel
21-349-2 PROM, DSP & I/O card
21-352-3 PROM, Output & Monitor card
23-200 Cue speaker
30-13 IEC line cord (USA style)
32-725 Rotary control knob
32-726 Fader knob (silver)
32-727 Fader knob (red)
32-728 Fader knob (green)
32-729 Fader knob (blue)
32-730 Fader knob (yellow)
38-307A M3x6 Silver hex screw (panel and fader screws)
50-27 In-Line Power Supply
70-160 Set-Up Stylus Tool
75-54 NetWave Installation & Operation Manual
80-1752 Lens (label)
80-1981-08 Palmrest (NetWave-8)
80-1981-16 Palmrest (NetWave-16)
80-1981-24 Palmrest (NetWave-24)
80-1982-1 Left side panel
80-1982-2 Right side panel
80-1983-08 Display window (NetWave-8)
80-1983-16 Display window (NetWave-16)
80-1983-24 Display window (NetWave-24)
80-1984-08 Reflector (NetWave-8)
80-1984-16 Reflector (NetWave-16)
80-1984-24 Reflector (NetWave-24)
80-1993-08 Connector access cover (NetWave-8)
80-1993-16 Connector access cover (NetWave-16)
Replacement Parts (cont.)
Harris # Description or Use
80-1993-24 Connector access cover (NetWave-24)
90-1858-1 15-foot DC cable (99-1205 power supply to console)
90-1997 Cue Speaker assy (23-200 speaker and cable)
90-1872-1 H/P jack assy (17-122 jack and cable), NetWave-8
90-1872-2 H/P jack assy (17-122 jack and cable), NetWave-16
90-1872-3 H/P jack assy (17-122 jack and cable), NetWave-24
90-1998-1 Serial Console display cable (NetWave-8 & -16)
90-1998-2 Serial Console display cable (NetWave-24)
90-2125 Blank Panel, two slots wide
95-1044 Fader Assembly (Dual Fader and Monitor panels)
INSTALLATION KITS
A console size-specific installation kit is shipped
with each new console.
76-1900-xx Installation Kit Parts
Harris # Description Qty for: -08 -16 -24
14-482 3-pin AMP MOD IV housing 12 20 28
14-484 6-pin AMP MOD IV housing 21 29 37
14-490 12-pin AMP MOD IV housing 8 16 24
14-492 14-pin AMP MOD IV housing 2 2 2
15-938-1 AMP MOD IV contact receptacles 286 454 622
80-2132 blank display lens 8 16 24
76-1901 Tool Kit (optional)
Harris # Description or Use Qty.
70-57 2mm Hex driver 1
70-126 AMP MOD IV crimp tool 1
70-129 AMP MOD IV pin extractor tool 1
88-175 Tool Pouch 1
OPTIONAL KITS
These kits can be installed at the time of con-
sole installation or any time thereafter.
Harris # Description or Use
99-1424 Dual Router Kit
99-1425 Link Activation Kit
99-1990-16Q Quad Meter Package for a NetWave-16
99-1990-24Q Quad Meter Package for a NetWave-24
