14
XG-100
BASI C SE T UP
2
ASSEMBLE THE RADIO
a. Make sure batteries are charged per the charger manual (refer to
10515-0372-4010, supplied with the charger).
b. To attach optional clip, slide into groove in back of the radio above
battery compartment.
c. Lift clip, if installed, and slide top of battery into top of battery
compartment at the rear of the radio.
d. Press down on bottom side of battery until it snaps into place.
Radio may need to be set for battery type (Battery Settings).
CAUTION: Do not overtighten the antenna as damage could result.
WARNING: Only use Harris charger approved for battery chemistry.
Injury could occur from improper charger use.
