Harris Unity XG-100P - Create Keygroup in the KVL 3000 Plus

47
XG-100
ADVANCED OPERATIONS
4
Create Keygroup in the KVL 3000 Plus
You can generate a group of Type-3 keys in the KVL 3000 Plus:
a. Turn on the KVL 3000 Plus.
b. Select Esc.
c. Select GROUPS.
d. Select NEW.
e. Enter a Group Name (up to seven characters).
NOTE
The XG-100 can store both DES-OFB and AES-256
keys, however, only one type may be loaded at a time.
A keyset must contain only DES-OFB or only AES-256
keys.
f. Select CKRs from the programmed list until all desired CKRs are
selected.
g. Select DONE. Refer to Load Keys for loading a keyset into the radio.
