XG-100
BASIC OPERATI ONS
3
XG-100P CONTROLS
1. CHANNEL KNOB
2. POWER / VOLUME
KNOB
3. ENCRYPTION
SWITCH
5. BANK SELECTOR
6. PROGRAMMABLE
HOT KEY
7. PTT BUTTON
8. PROGRAMMABLE
BUTTONS
18. SOFT KEYS
19. SELECT/SHORTCUT
BUTTON
20. NAVIGATOR
21. KEYPAD**
17. SOFT-KEY
DISPLAYS
CL-0372-4200-0005B
14. SPEAKER
15. MICROPHONE*
16. FRONT DISPLAY
11. EMERGENCY
BUTTON
12. INDICATOR LED
13. TOP DISPLAY
10. ANTENNA
CONNECTOR
9. BATTERY
4. MICROPHONE*
(REAR)
*DUAL MICROPHONE SYSTEM
USED FOR NOISE CANCELLATION
** USE
AS HOME KEY FOR
NAVIGATION BACK TO MAIN SCREEN
