Monitor and Squelch Types
The monitor function allows you to temporarily turn off selected squelch to monitor
for traffic that may not normally break squelch. Squelch used depends on an
analog or digital channel.
For analog channels, there is:
• Noise squelch - any received signal breaks squelch.
• Continuous Tone Coded Squelch (CTCSS) - squelch is selective based
on tone code.
• Continuous Digital Coded Squelch (CDCSS) - squelch is selective
based on tone code.
For digital channels, there is:
• Monitor squelch - any received digital signal breaks squelch.
• Normal squelch - Received Network Access Code (NAC) breaks
squelch.
• Selective squelch - Received NAC and talkgroup Identification (ID) or
unit ID breaks squelch.
1. Enter Shortcut Menu.
START MONITOR is grayed
when radio is scanning.
2. Use to select
START MONITOR.
3. Use to toggle the
monitor ON or OFF.
