6
SPECIFICATIONS
UNIT DIMENSIONS AND WEIGHTS
TRAY 15.0KW 20.0KW RESERVOIR
Height
18.63" 18.63" 13.9"
Width
16.15" 16.15" 19"
Length
43.38" 43.38" 9.3"
Weight
350 lbs 384 lbs
Max KW
15 20
Amps @ 120V
125 167
Amps @ 240V
63 84
Power Required
34 HP 44 HP
Max System
Pressure
3900 PSI 4600 PSI
ALTERNATOR DETAIL
Design: Brushless revolving field, four pole, and 1800 rpm for 60-hertz operation.
Rating: See nameplate for individual unit rating.
Regulation: ± 1% Voltage regulation from nameplate rating.
Waveform: Harmonic distortion is limited to just 4%.
Insulation: Class H, 200°C, Slot Insulation, Varnish, Additional Marine Coating.
Power Factor, Pf: 1.0 (unity) for single phase units, 0.8 for three phase units.
HYDRAULIC SYSTEM
Type of oil: Use only premium hydraulic fluid with anti wear, anti foam, and anti rust additives.
Optimum operating viscosity is 80-170 SUS. Viscosity should never exceed 4,600 SUS at
the coldest startup temperature, and should never be less than 60 SUS at 180°F.
Capacity: The reservoir should contain a minimum of 5.0 gallons (U.S.) of hydraulic oil.
DRIVE MOTOR
Type: Bent-axis piston motor
Displacement: 30 CC
Max. Pressure: 5800 psi
Case Drain: External
Rotation: Bi-Directional
PUMP REQUIREMENTS
Flow: 15.0 GPM
Pressure: 3900 psi
