3
INTRODUCTION
ABOUT THIS MANUAL
This manual covers the specifications, installation,
operation, and maintenance of your Harrison Hydra-
Gen hydraulic generator.
PARTS & SERVICE
To obtain parts or service, please have your model
and serial number ready and contact us toll free at
1-800-723-3334. Outside of the United States, please
call 1-281-807-4420. You can also reach us via fax at
1-281-807-4815. Our office hours are Monday
through Friday between 8:00 AM and 5:00 PM
Central Standard Time.
Alternately, you may access product information
online at www.harrisonhydragen.com and obtain
support via customerservice@harrisonhydragen.com.
SYSTEM OVERVIEW
Harrison Hydra-Gen hydraulic generators are
comprised of several components. A general
hydraulic and electrical component overview for our
generator is described below.
• Hydraulic Pump: The hydraulic pump sends
hydraulic fluid (oil) to the motor at a constant
flow under varying engine speeds.
• Motor: The hydraulic motor drives the
alternator.
• Alternator: An AC brushless revolving field
alternator provides regulated 120/240 VAC.
• Heat Exchanger: When the oil leaves the motor
it is cooled in an oil-to-air heat exchanger before
it is returned to the reservoir.
• Hydraulic Reservoir: The hydraulic oil
reservoir is equipped with an oil filter, oil level
sight glass, oil temperature gauge, oil filter and
breather cap.
• Display: The generator is also equipped with a
FRC meter which displays output voltage,
frequency, current, oil temperature, and unit
running time.
