51
14
7 09 15 107 3001 09 15 107 3101
7 09 15 107 2602 09 15 107 2702
7 09 15 107 2603 09 15 107 2703
Crimp termination;
7 x 2 mm contacts
Solder termination
PCB solder-in termination
1)
Contact Part number Drawing
Identification number Male insert Female insert Dimensions, in mm
Male Female
1)
Only for use with bulkhead mounted housings: 09 15 100 0301, 09 15 100 0302, 09 15 100 0305, 09 15 100 0306 and 09 15 100 0307
Han
®
M23 Signal Inserts
