HARTING Han M23 - Han M23 Signal Assembly Instructions

51
24
4 mm
4 mm
①①
②②
③③
④④
⑤⑤
⑥⑥
Crimping*
Coding
Crimping*
Coding
Han
®
M23 Signal, bulkhead mounted housing
* Refer to the operating instructions for the crimping tool
09 99 000 0890 or 09 99 000 0896.
* Refer to the operating instructions for the crimping tool
09 99 000 0890 or 09 99 000 0896.
Click!
Click!
Click!
Click!
Click!
Click!
Male Female
Han
®
M23 Signal Assembly instructions
