Technical characteristics
Derating and EMC diagram
Hoods and housings
Material Copper zinc alloy
Surface Nickel plated
Seal NBR
Limiting temperatures -40 °C … +125 °C
Degree of protection and seal in locked position IP67 / IP69K
Clamping range 3 – 17 mm
Inserts
Material Thermoplastic polyamid
Termination technique Crimp, solder, solder-in
Number of poles 6 7 9 12 17 19
Number of contacts 6 7 8 1 12 17 16 3
Contact Ø mm 2 2 1 2 1 1 1 1.5
Rated current A 20 20 8 20 8 8 8 10
Rated voltage
1)
V 300 300 200 200 160 100
Test voltage V 2500 2500 2500 2500 1500 1500
Insulation resistance MΩ > 10
10
> 10
10
> 10
10
> 10
10
> 10
6
> 10
6
Max. contact resistance mΩ 333333
1) According to DIN VDE 0627, metallic parts which may be touched by a person and may have voltages present under fault conditions must have
integral protection.
Operating current [A]
Ambient temperature [
o
C]
The current carrying capacity is limited by maximum temperature
of materials for inserts and contacts including terminals. The
current capacity-curve is valid for continuous, non-interrupted
current-loaded contacts of connectors when simultaneous
power on all contacts is given, without exceeding the maximum
temperature.
Control and testing procedures, according to DIN IEC 60512-5-2.
12 poles insert,
conductor
cross-section:
1.00 mm²
Transfer impedance [mΩ]
Frequency [Hz]
Han
®
