51
38
09 15 600 9102
09 15 600 9103
09 99 000 0896
1)
09 99 000 0890
Screw cover for bulkhead
mounted and cable to cable
housings,
with chain (100 mm)
Screw cover for hoods,
with chain (100 mm)
Four-indent crimping tool
for power and signal contacts
1)
Han
®
M23 Four-indent crimping
tool – for signal contacts
Drawing
Identification Part number Dimensions, in mm
1)
Not suitable for 0.6 mm data contacts
Han
®
M23 Power / Hybrid Accessories
