51
32
09 15 600 0301
09 15 600 0302
09 15 600 0902
09 15 600 0912
Bulkhead mounted housing,
front wall assembly
O-ring seal (4 x 2.7 mm)
Bulkhead mounted housing,
front wall assembly
O-ring seal (4 x 3.2 mm)
Bulkhead mounted housing,
angled
25 x 25 mm
O-ring seal (4 x 2.7 mm)
Bulkhead mounted housing,
angled
28 x 28 mm
O-ring seal (4 x 3.2 mm)
Drawing
Identification Part number Dimensions, in mm
Panel cut out Ø 20
Panel cut out Ø 20
Panel cut out Ø 20
Panel cut out Ø 20
Han
®
M23 Power / Hybrid Bulkhead mounted housings
