HARTING Han M23 - Page 36

51
36
09 15 609 3011
9
09 15 609 3111
09 15 612 3001
12
09 15 612 3101
09 15 609 3001
9
09 15 609 3101
Han
®
M23 P
5 + 3 + PE (B)
Crimp termination
5 x 1 mm contacts
4 x 2 mm contacts
Han
®
M23 P Hybrid
4 + 4 + 3 PE
Crimp termination
4 x 0.60 mm contacts
4 x 1.00 mm contacts
4 x 2.00 mm contacts
Contact Part number Drawing
Identification number Male insert Female insert Dimensions, in mm
Han
®
M23 P
5 + 3 + PE (A)
Crimp termination
5 x 1 mm contacts
4 x 2 mm contacts
Han
®
M23 Power / Hybrid Inserts
