HASE LUNO - BOLTING YOUR LUNO GAS STOVE TO A PERMANENT STRUCTURE

HearthStone Quality Home Heating Products, Inc. LUNO 8160 Gas-Fired Direct-
Vent
PARTS LIST:
Part # Part Name
7211-252 BURNER PAN
7211-253 BURNER TOP PLATE
7211-250 VENTURI TUBE
5800-240 SHUTTER: PRIMARY AIR
3160-181 GASKET: FIREBOX BOTTOM
3160-180 BURNER GASKET
3160-152 PILOT GASKET
3160-182 VENTURI GASKET
3170-150 PLATINUM BRIGHT EMBERS
7211-572 REAR LEFT LOG
7211-573 REAR RIGHT LOG
7211-574 CENTER EMBER PILE
7211-575 CENTER VERTICAL LOG
7211-576 FRONT, RIGHT LOG
7211-577 FRONT, LEFT LOG
7211-578 TOP TWIG
7211-517 KIBBLES (4OZ)
7211-401 KNOB EXTENSION ON/OFF
7211-402 KNOB EXTENSION HIGH/LOW
7211-370 PILOT ASSEMBLY (NG) 3 port
7200-338 NG ORIFICE MAIN ORIFICE #38 SPUD
91-56800 LP CONVERSION KIT
91-56803
HIGH ALTITUDE COVERSION KIT (LP
ONLY)
1141-820-128-0102 TOP STONE PLATE
5120-020 PILOT SHIELD
WARNING: DO NOT SUBSTITUTE MATERIALS. FOR
REPLACEMENT PARTS, OR FOR INFORMATION ABOUT
PARTS OR SERVICE, CONTACT YOUR AUTHORIZED
HEARTHSTONE RETAILER. FOR THE NAME OF THE
AUTHORIZED RETAILER NEAREST TO YOU, VISIT OUR
WEBSITE WWW.HEARTHSTONESTOVES.COM, OR
WRITE:
Hearthstone Quality Home Heating Products, Inc.
317 Stafford Ave.
Morrisville, Vermont 05661-8695
E-Mail: inquiry@Hearthstonestoves.com
BOLTING YOUR LUNO GAS
STOVE TO A PERMANENT
STRUCTURE
When installing the Luno in a mobile home it is
required that you attach it to the structure. To do
this, we have provided a rear attachment kit with the
unit. Locate the 2 steel plates and remove them from
the packaging. Attach the first (inner) plate to the
stove by inserting the angled end into either the
upper (shown) or lower slot (invert inner plate)
located in the rear of the stove housing. (See figures
13 & 14) Attach the second (outer) steel plate to the
first one using the 2 allen screws provided (See
Figures 13 & 14). The rear or outer plate can be
installed with the flange up or down as desired. We
recommend securing the kit directly to suitable wall
framing – not drywall sheeting.
