HASE LUNO - SPECIFICATIONS

HearthStone Quality Home Heating Products, Inc. Luno Model #8160
SPECIFICATIONS
Listed as: Gas-Fired Direct-Vent Fireplace Heater
Model: Luno Direct-Vent Gas Fireplace Heater
(Model #8160)
Testing Agency: Intertek Testing Services
Tested to: ANSI Z21.88b-2005/CSA 2.33b-2005,
CGA 2.17-M91
Report No. 3092115-T4
Certified for US and Canada
Approved for Mobile Home Installation.
Certified for use by:
Board of State Examiners of Plumbers and Gasfitters
100 Cambridge Street, Room 1511
Boston, Massachusetts 02202
FUEL TYPE: NG LP
INPUT RATING (Btu/hr) 0-2000 ft 26,500 26,500
INPUT RATING (Btu/hr) 2000-4000 ft 26,500 26,000
ORIFICE SIZE (DMS) 0-2000 ft 38 52
ORIFICE SIZE (DMS) 2000-4500ft) 38 53
MANIFOLD PRESSURE - LO SETTING (in. W.c./kpa) 1.2/0.3 3.3/0.8
MANIFOLD PRESSURE - HI SETTING (in. W.c./kpa) 3.5/0.87 10.0/2.48
MINIMUM INLET PRESSURE - (in.w.c./kpa) 5.0/1.24 11.0/2.88
MAXIMUM INLET PRESSURE- (in.w.c./kpa) 7.0/1.74 13.0/3.22
MINIMUM INPUT RATING (btu/hr) 16,000 15,000
MAXIMUM OUTPUT (btu/hr) 0-2000 ft 20,400 20,200
Table 1 - Luno Fuel and Output Specifications
Figure 1 – Luno 8160 Dimensions
3
