HATO 200 - Page 11

11
Step 4.
Close the door.
Place the drive unit in the center of the floor. Lift the front end of the runner up to the wall bracket
that is fitted above the garage door. Insert bolt and lock with nut.
M8 EXPANSION BOLTS
(NOT INCLUDED IN THE SET)
GUIDE END
WALL MOUNT
WALL MOUNTING
SCREW WITH A GUIDE
