3. Installation
ATTENTION !
Before starting the assembly, make sure that all the recommendations of section 1.2 are met
3.1. Assembly
Step 1.
Check that the door is well balanced and free to move by manually opening and closing it. Make
sure the center section of the wall above the door is strong enough to support the wall bracket.
Close the door. Measure the door width, mark the center with a pencil, then draw a line down the
door and up on the wall above it. Check the height at which the drive should be mounted. To do this,
slowly open the garage door and observe when the door reaches its highest point in its movement.
Close the door again and mark this point on the wall. Then draw it on the wall a horizontal line
crossing the vertical center line approximately 40 mm above the highest marked point. (Note: the
distance from the horizontal line to the ceiling should be 80mm. If there is not enough space, please
use the maximum possible height that allows you to properly fix the wall bracket.)
