Hatz 2M41 - EPA EMISSION CONTROL WARRANTY STATEMENT

2L41C, 2M41, 2M41Z EPA CERTIFIED ENGINES
HATZ
101Operator’s Manual
INSTRUCTIONS ON THE INSTALLATION OF THE EXHAUST SYSTEM
Following are the instructions to properly install the exhaust system and re-
lated components consistent with the EPA emission regulation requirements.
2M41, 3M41, 4M41
2
1
5
6
3
4
Exhaust-silencers
The exhaust silencer is fitted in connection with gaskets.
Fixation is done by hexagon head screws (1) and Allen screws (3).
Dismantling:
▪ Remove in numerical sequence (1...5).
Assembly:
▪ Assemble in reverse sequence.
▪ Use anti-seize compound J as specified by HATZ.
