Hawle E2 - Modification of a standard valve DN250-600 with an adapter for an electric actuator

12 | P a g e
7. Attach the spindle socket and the spigot onto
the spindle in the lantern.
8. Completely mounted lantern.
C7 Modification of a standard valve DN250-600 with an adapter for an electric actuator
1. Remove the wax sealing from the centering flange
screws.
2. Loosen the inner hex bolts and remove
them.
3. Remove the centering flange.
4. In case the upper ball bearing or the bearing
ring remains in the central flange, take them
out.
