3 | P a g e
A3 Labeling
Every valve is labeled as follows
The type plate should not be covered up so that the installed fitting remains identifiable.
A4 Transport, Storage and Handling
Note:
Additional information may be contained in the instruction manual of the drive, which must also be
adhered to.
Transport and Storage:
The valve must be kept in the factory packaging in an opened condition until installation. The fittings
must be stored in clean and dry rooms and be protected from dirt, moisture and other contamination.
The valve may not continuously be exposed to direct sunlight as the coating is not resistant to UV
radiation. If intermediate storage outdoors is required, package the valve in thick plastic foil for
protection from dirt.
The fitting was packaged in accordance with the ordering conditions. In the
event of any transport damage, please notify the shipping company in writing.
The indicated "Max. MOP" is the maximum permissible operating pressure.
In case of further inquiries to the manufacturer, Hawle Armaturenwerke GmbH,
the "Serial Number" according to the type plate must be indicated.
DN XXX: (mm) Nominal Width
PN XX: (bar) Pressure Class of Housing
Serial Number: Year of Manufacture, individual
Hawle Works Number
