DisengagingtheBlade
Releasethebladecontrolbar.
Important:Whenyoureleasethebladecontrol
bar,thebladeshouldstopwithin3seconds.Ifit
doesnotstopproperly,stopusingyourmower
immediatelyandcontactanAuthorizedService
Dealer.
OperatingtheTractionDrive
EngagingtheTractionDrive
1.Releasethetractioncontrolbar(Figure16).
Figure16
2.Movethegroundspeedcontrollevertothedesired
gearposition.
3.Squeezethetractioncontrolbaragainstthehandle
(Figure17).
Figure17
DisengagingtheTractionDrive
Releasethetractioncontrolbar.
CheckingtheBladeBrake
Clutch
Checkthebladecontrolbarbeforeeachusetoensure
thatthebladebrakeclutchsystemisoperatingproperly.
Youcanusethegrassbagtoperformanadditionaltest
tocheckthebladebrakeclutchmechanism:
1.Installtheemptygrassbagonthedischargetunnel.
2.Starttheengine.
3.Pullthebladecontrolbartothenormalblade
engagedposition.Thebagshouldbegintoinate,
indicatingthatthebladeisengagedandrotating.
4.Releasethebladecontrolbail.Ifthebagdoesnot
immediatelydeate,itindicatesthatthebladeisstill
rotating.Thebladebrakeclutchmechanismmay
bedeteriorating,and,ifignored,couldresultinan
unsafeoperatingcondition.Havethelawnmower
inspectedandservicedbyanAuthorizedService
Dealer.
Ifthebladebrakeclutchsystemisinoperative,
thebladewillcontinuetorotatewhenyou
releasethebladecontrolbail.Contactwith
bladecouldoccur,causingseriousinjury.
•Checkthebladebrakeclutchoperation
beforeeachuse.
•Neveruseamowerequippedwithablade
brakeclutchthathasaninoperativesafety
system.
•TakeyourmowertoanAuthorizedService
Dealerforrepairifthesafetysystemfailsto
operateproperly.
AdjustingtheCuttingHeight
Eachwheelisadjustedindividuallywithawheelheight
adjustmentlever.Cuttingheightsare1inch(25mm),
1-1/2inches(38mm),2inches(51mm),2-1/2inches
(64mm),3inches(76mm),and3-1/2inches(89mm),
and4inches(102mm).
