Hayter 455E - Fuel System and Engine Oil Setup; Installing Fuel Tank and Fuel Line; Filling the Engine Crankcase with Oil

2
InstallingtheFuelTankand
theFuelLine
Partsneededforthisprocedure:
2
Self-tappingscrew
1Fueltank
Procedure
1.Slidetheendofthefuellineontotheelbowtting
(Figure4).
G002527
1
2
3
4
Figure4
1.Fueltank3.Fuelline
2.Elbowtting
4.Fuellineclamp
2.Securethefuellineinplacewiththefuellineclamp
(Figure4).
3.Slidetheplasticclipsonthefrontofthefueltank
ontothefueltankmount(Figure5).
Figure5
1.Plasticclip(2)
4.Securethebottomofthefueltanktothefueltank
bracketbyinstallingtheself-tappingscrewsfromthe
bottom.Torquethescrewsto40to50in-lb(4.5
to5.6N-m).Donotovertightenthescrews.
3
FillingtheCrankcasewithOil
NoPartsRequired
Procedure
Theenginecrankcaseisshippedwithoutoil.Youmust
llitwithapproximately30oz.(0.88L)ofoilbefore
startingtheengine.RefertoCheckingtheEngineOil
LevelintheOperationsectionforoilspecicationsand
instructions.
