Hayter 455E - Blade Brake Cable Adjustment Details

Figure33
1.Spring3.Cableclampscrew
2.Brakecableconduit
6.Holdthebladecontrolbarsothattheoutsideofthe
baris5-1/2inches(14cm)fromtheoutsideofthe
handle,andpullthecabletotheremovetheslack,
butdonotputtensiononthespring(Figure34).
Figure34
1.5-1/2inches(14cm)
3.Bladecontrolbar
2.Handle
7.Torquethecableclampscrewto100to120in-lb(11
to14N-m)tolocktheadjustmentinplace.
Donotovertightenthebladebrakecable.
Overtighteningthebladebrakecablecould
preventthebladebrakefromcontactingthe
brakedrumwhenyoureleasethecontrolbar.
Ifthebladebrakedoesnotcontactthebrake
drum,thebladewillnotstoprotating,which
couldcauseseriouspersonalinjury.
•Eachtimeyouadjustthebrakecable,ensure
thatthebrakestopsthebladein3seconds
orless.
•Ifthebladedoesnotstoprotatingin3
secondsorless,bringthemowertoan
AuthorizedServiceDealerforinspection
andrepair.
24
