Hayter CODE613A - Assembling the Grass Bag

15
EN
3. Insert the cables into the cable clamp and attach the cable clip to the handle. Figure 7.
Figure 7
1. Cable clip
Assembling the Grass Bag
1. Slide the grass bag frame (1) into the grass bag. Figure 8.
2. Position all 6 grass bag clips (2) over the grass bag frame. Figure 8.
1
2
Figure 8
1. Grass Bag Frame
2. Grass Bag Clip
