Operation
Note: Determine the left and right sides of the machine from the normal operating position.
Before Operation
Inserting the Electric-Start Button
Remove the electric-start button from the plastic parts bag and insert it into the electric starter. Figure 10.
1
2
Figure 10
1. Electric-start button
2. Electric starter
Installing the Battery Pack
Important: Operate the battery pack only in temperatures that are within the appropriate range; refer to
Specifications.
1. Make sure that the vents on the battery are clear of any dust and debris.
2. Lift up the battery compartment lid. Figure 11A.
3. Line up the cavity in the battery pack with the tongue on the machine and slide the battery pack into
the compartment until it locks into place. Figure 11B.
4. Close the battery compartment lid. Figure 11C.
Note: If the battery-compartment lid does not close completely, the battery is not fully installed.
A B C
Figure 11
