Hayter MT313 - DECALS; Decal - Jacking; Support Point; Decal - Engine Fan; Radiator; Decal - Tyre Pressure

995901PM140404A
SAFETY PRECAUTIONS
DECALS Continued.
1.13
1.13
HEIZKORPERDECKELENTFERNENERSTWENN DER MOTORKUHLIST.
ONLY REMOVE RADIATORCAP WHEN ENGINEIS COOL.
VERWIJDERDE RADIATORDOPPASNADAT DE MOTORISAFGEKOELD.
IL FAUTTOUJOURSATTENDRELE REFROIDISSEMENTDU MOTEUR
AVANTDERETIRERLE BOUCHONDURADIATEUR.
70-13-073 REV (.0.)
Decal - Jacking / Support Point Part No: 70-13-072
Location: Front Axle - 2 Points
a) Jacking and Support Point
Decal - Engine Fan / Radiator Part No: 70-13-073
Location: Engine Fan Cowl
a) Danger of Severing Fingers
b) Caution
c) Warning - Hot Surfaces
Decal - Tyre Pressure Part No. 995905
Location: LH/RH Chassis.
a) Tyre Pressure
b) Mowing & Road Travel all 3 Tyres
Decal - Platform Lift Warning Part No. 995912
Location: On Right Hand Rear Platform
a) Warning of heavy operator Platform
b) Take care when lifting and working under Platform.
Decal - Control Pedal Part No: 995908
Location: In front of seat on Platform
a) Forward Speed (continuously variable)
b) Reverse Speed (continuously variable)
Decal - Warning Platform Secure
Part No. 995910
Location: Either side of Operator Seat
a) Warning - Prevent Accidents: Operator platform can
raise if not correctly secured.
b) Ensure platform is correctly seated and both fasten-
ers replaced and to correct torque before operating
the machine
