995901PM140404A
MAINTENANCE
5) The steering must be operated manually when the mower is being towed. The steering will feel
heavy as there is no hydraulic
assistance when the engine is switched off.
6) After towing the mower: To return the mower to its normal working condition the following pro-
cedure must be adopted:
1) Place the parking brake lever in the “brakes on position”
2) Chock the front wheels and re-commission the hydraulic service braking system as follows.
3) Close the 2 bypass valves. and tighten to a torque of 41- 68 Nm.
4) Remove the wheel chocks.
5) Disconnect the tow bar.
The mower braking system will now operate in the normal way.
WARNING: PREVENT ACCIDENTS - Before using the mower, ensure that the braking system
operates correctly. Carry out initial checks with the mower at slow speed. Do not operate the
mower with a defective braking system. Do not operate the mower with the brakes de-commis-
sioned.
TOWING THE MOWER Continued.
1.59
1.59
