995901PM140404A
HYDRAULIC CIRCUIT DIAGRAM
1.73
1.73
NO. DESCRIPTION PART NO.
1 Transmission Pump 995610
2 Relief valve – charge circuit – 18.5 bar -
3 Relief valve – forward travel – 250bar -
4 Relief valve – reverse travel – 250bar -
5 Shuttle valve – hot oil purge 995618
6 Check valve – transmission forward bypass -
7 Check valve – transmission reverse bypass -
8 Flow control orifice – hot oil purge 995620
9 Wheel motor - rear 995616
10 Wheel motor – front RH with brakes 995615
11 Wheel motor – front LH with brakes 995615
12 Flow control orifice – rear wheel motor bypass 995619
13 Gear pump – cutterhead drive 70-06-151
14 Gear pump – steering and cutterhead lift 70-06-151
15 Relief valve – steering and lift -
16 Hydraulic motor – centre cutterhead 910696
17 Check valve/orifice – motor bypass centre cutterhead -
18 Hydraulic motor – front LH cutterhead 940602
19 Check valve/orifice – motor bypass LH cutterhead -
20 Diverter valve – LH cutterhead 953601
21 Hydraulic motor – front RH cutterhead 910696
22 Check valve/orifice – motor bypass RH cutterhead -
23 Diverter valve – RH cutterhead 953601
24 Steering unit 995609
25 Relief valve – steering unit -
26 Steering cylinder – rear wheel 995814
27 Hydraulic oil filter 995605
28 Solenoid valve and sub plate - cutter 70-06-245
Sub plate – solenoid cutter valve -
29 Relief valve – cutter -
30 Valve – cutterhead lift 995608
31 Cylinder – centre cutterhead lift 910109
32 Cylinder – LH cutterhead lift 910109
33 Cylinder – RH cutterhead lift 910109
34 Valve – cutterhead weight transfer 995627
35 Valve – park brake 995611
36 Hand pump – manual brake release (optional) 995621
37 Relief valve – manual brake release (optional) 995683
38 Hydraulic oil cooler 995614
39 Hydraulic oil tank 995824
40 Suction element 65-06-305
