Remove cell cable from the cell vessel by turning the lock
nut counter clockwise and removing cable. Unplug the
cell cable from the PCB. Cell cable plug is shown in the
picture to the right. Go to next step.
Slowly separate the front cover from the back of the
AQR100 and move it towards the top of the unit. Be
mindful not to damage the membrane cable as itwill
remain connected to the PCB. Go to next step.
Disconnect Cell CableRemove Front Cover
How To: Test/Replace Cell Cord (Cont.)
Remove cell
cable from cell
vessel
15
