System Startup
After confirming that all wiring has been performed according to NEC and local codes and that the
Hub is properly grounded, apply power to the VS Omni. The VS Omni will take about 30 seconds to
fully start.
Firmware Upgrade
The VS Omni's firmware is the basic operating system that runs the system. The VS Omni was
shipped with the version of firmware that was available at the time of release. There may be a newer
version available and if so, we encourage you to upgrade. Also, if you have experienced problems,
Hayward Technical Support may advise you to upgrade your VS Omni's firmware. To upgrade the
VS Omni firmware, refer to the procedure shown in the VS Omni Operation Manual. Upgrading
firmware can be performed before or after Configuration but should be done before the VS Omni
begins operation.
Configuration
Initial Configuration
Because this is the first time that the VS Omni has been powered on, it will bring you directly to the
initial configuration screen shown below. Note that the VS Omni Control Pad uses a resistive touch
screen that is appropriate for a pool environment. It requires a deliberate push when selecting a
button. At the initial configuration screen, touch the “en” button to select a language (the default
language is English) and then touch “OK” to begin configuration. After pressing “OK” you will be
prompted to select the type of configuration wizard that you would like to use as shown below. See
the descriptions in the “About the Configuration Wizard” section for information about each type of
configuration wizard so that you can choose the right one to fit your needs and make configuration
as simple as possible.
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
22
OK
en
Welcome to the Hayward Pool Controller
Press OK to congure your pool.
Pre Programmed Config (VSP, Htr, Lt)
New Typical Configuration
New Advanced Configuration
Load Existing Configuration
System Options
To Next Page
Loading...
