Before you Begin
What’s Included
Check that the following components have been included in your package:
• VS Omni Hub
• Control Pad
• Smart Relay
• 2 Temperature Sensors
• Variable Speed Pump (VSP)
• 15 ft, 3 conductor (red, black and bare wire) communication cable to connect Hub to VSP
• 2 Wiring Whips - 6 ft flexible conduit containing three 12AWG conductors (red, black and
green) for wiring VSP to VS Omni Hub and for Smart Relay installation). A length of white 12
AWG conductor is included to replace red for 115V Smart Relay applications
• Input Power Wiring harness and miscellaneous installation hardware
What’s NOT Included
Some of the additional items that you may need to complete an installation include:
Wire
Wire/conduit for incoming power
Wire for remote heater control and other low voltage devices
Ethernet cable (if not using wifi)
Miscellaneous
Valve actuator to automate pool functions (see page 9)
Flow switch for pump protection/flow monitoring
Mounting hardware for mounting Hub, Control Pad and Smart Relay
Cable/cord connectors to provide knockout strain relief
Wire nut connectors
USB thumbstick (to update firmware)
Tools Needed
Philips and flat screwdrivers
Wire cutters and strippers
Knife to cut conduit
Drill and drill bits (including 3/8")
Pliers
Level
Accessory Products - Order Separately
HLH485RELAY Smart Relay used for controlling additional pool equipment
FLO Flow Switch used to detect water flow
GVA-24 Valve Actuator
2PC Temperature Sensor for 3rd input
3
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
