SPEED PRIORITIES (NON-EXTERNAL CONTROL)
For schedule duration settings, SPEEDs are prioritized as follows: SPEED1 -> SPEED2 -> SPEED3 -> SPEED4.
SPEED1 is the highest priority, while SPEED4 is the lowest.
If you setup overlapped schedule, the pump will perform according to the speed priority.
Example:
Starting Schedule (Before Adjustment)
SPEED 1 start time= 8:00AM duration= 6 hours
SPEED 2 start time= 9:00AM duration= 1 hours
SPEED 3 start time= 10:00AM duration= 1hours
SPEED 4 start time= 2:00PM duration= 1 hours
In this way, according to the priority, the water pump will run the speed 1 mode from 8:00 a.m. to 2:00 p.m. (skip the speed
2 and 3 modes in the middle, because speed 2 and 3 have been included in the speed 1 operation period), and the speed
4 mode will run from 2:00 p.m.to 3:00p.m.
End Schedule (After Adjustment)
SPEED 1 start time= 8:00AM duration= 6 hours
SPEED 4 start time= 2:00PM duration= 1 hours
OPERATING THE PUMP WHILE RUNNING
• CAUTION - If power is connected to the pump, pressing any of the following buttons referred to in this section could result
in the motor starting. Failure to recognize this could resultin personal injury or damage to equipment.
Pressingthe Display button will cycle through the current.
Speed — current run speed
Time — current time of day
Duration — amount of time remaining at current run speed
Watts — watts currently being consumed
Pressing any of the SPEED Buttons(“1”,“2”,“3”,“4”or Quick Clean) while the pump is running will act as a temporary over
ride. The pump will run the speed and duration programmed for that button. Once completed the pump will return to the
appropriate point in the programmed schedule.
Note: If schedule speeds are adjusted while the pump is running, the pump will run the entered speed for the rest of
theprogram's duration, but will not save the adjustments.
MANUAL MODE TO AUTO MODE OR IN REVERT
• When the pump is on priming, if you press anyone of speed button, it will exit priming and enter manual mode. If you
press speed, it will run 20 min; If you press speed 2 or 3, it will run 10 min; And if you press speed 4, it will pause, because
the duration is 0. After the duration is completed, the motor will compare the current time and the schedule time. If current
time is covered by the schedule, it will run the higher priority schedule which meet the time request(enter auto mode).
• Once the allotted time for the manual mode has elapsed, the auto mode will commence.
