Only use spare parts supplied by Hayward
®
Brand
Page 9 on 22Xxxxxx xxxx
EN
English
PAUSE UNDER AUTO MODE
• It's easy to pause under auto mode(programmed schedule). Suppose we have a schedule below:
The program Start up time Duration Speed
The cycle is 22 hours a day
Speed 1
8:00AM(8:00)
(adjustable)
2H(adjustable)
2400 RPM
(adjustable)
Speed 2
10:00AM(10:00)
(adjustable)
10H(adjustable)
1500 RPM
(adjustable)
Speed 3
8:00PM(20:00)
(adjustable)
2H(adjustable)
2000 RPM
(adjustable)
Speed 4
10:00PM(22:00)
(adjustable)
8H(adjustable)
1000 RPM
(adjustable)
• If we want to pause 2h from 10:00 AM to 12:00 PM(noon), the schedule will be like this:
The program Start up time Duration Speed
The cycle is 20 hours a day
Speed 1
8:00AM(8:00)
(adjustable)
2H(adjustable)
2400 RPM
(adjustable)
Speed 2
12:00AM(12:00)
(adjustable)
8H(adjustable)
1500 RPM
(adjustable)
Speed 3
8:00PM(20:00)
(adjustable)
2H(adjustable)
2000 RPM
(adjustable)
Speed 4
10:00PM(22:00)
(adjustable)
8H(adjustable)
1000 RPM
(adjustable)
End time of speed 1 is 10:00 AM and the start up time of speed 2 is 12:00 AM, so the pump will pause 2h.
• If we want to pause the pump from 8:00 PM to 8:00 AM of the next day, the schedule can be like this:
The program Start up time Duration Speed
The cycle is 12 hours a day
Speed 1
8:00AM(8:00)
(adjustable)
1H(adjustable)
2400 RPM
(adjustable)
Speed 2
9:00AM(9:00)
(adjustable)
6H(adjustable)
1500 RPM
(adjustable)
Speed 3
3:00PM(15:00)
(adjustable)
1H(adjustable)
2000 RPM
(adjustable)
Speed 4
4:00PM(16:00)
(adjustable)
4H(adjustable)
1000 RPM
(adjustable)
• The end time of speed 2 is 8:00 PM, and the start up time of speed 3 is 8:00 AM, so the pump will pause 12h, and when
the time is 8:00 AM next day, speed 3 will be covered by speed 1 for the lower priority, and speed 4 is the lowest priority
The program Start up time Duration Speed
The cycle is12 hours a day
Speed 1
8:00AM(8:00)
(adjustable)
2H(adjustable)
2400 RPM
(adjustable)
Speed 2
10:00AM(10:00)
(adjustable)
10H(adjustable)
1500 RPM
(adjustable)
Speed 3
8:00PM(20:00)
(adjustable)
2H(adjustable)
2000 RPM
(adjustable)
Speed 4
10:00PM(22:00)
(adjustable)
8H(adjustable)
1000 RPM
(adjustable)
