OPERATION
Before operating the pump for the rst time, the pump’s internal clock and operational schedules must be programmed by
following the steps in this manual. Refer to Setting the Clock and Programming Custom Schedules, for instructions
regarding the programming of this pump for scheduled operation.
Note: When programming a new schedule, please program the start time of speed 1- 4 according to the time sequence
of one day.
SETTING THE CLOCK
When power is rst connected to the pump the clock will blink to indicate that is has not been set. Custom schedules are
based on this clock setting, so the clock must be set rst.
1. Press Setting .
2. Use “+” and “-” to program the current time
Use “<” and “>” to moving the modify cursor
Note: In the 12 hours time format AM/PM will
display on the left.
USING THE DEFAULT SCHEDULE
The default schedule is designed to provide sufcient daily turnover for a typical pool. See Table 2 for default schedule.
THE PROGRAM START UP TIME TIEM OF OPERATION DEFAULT SPEED
THE DEFAULT CYCLE IS 22 HOURS A DAY
SPEED1
8:00 AM (8:00)
(ADJUSTABLE)
2H (ADJUSTABLE)
2400 rpm
(ADJUSTABLE)
SPEED2
10:00 AM (10:00)
(ADJUSTABLE)
10H (ADJUSTABLE)
1500 rpm
(adjustable)
SPEED3
8:00 PM (20:00)
(ADJUSTABLE)
2H (ADJUSTABLE)
2000 rpm
(adjustable)
SPEED4
10:00 PM (22:00)
(ADJUSTABLE)
8H (ADJUSTABLE)
1000 rpm
(adjustable)
The default schedule will operate as follows:
1. SPEED 1 will begin at 8:00am and run at 2400 RPM for a duration of 2 hours.
2. SPEED 2 will begin at 10:00am and run at 1500 RPM for a duration of 10 hours.
3. SPEED 3 will begin at 8:00pm and run at 2000 RPM for a duration of 2 hours.
4. SPEED 4 will begin at 10:00pm and run at 1000 RPM for a duration of 8 hours.
5. At the end of speed 4, the pump will stop running for 2 hours and then run speed 1 again. Because the factory is set
to run continuously for 22 hours every day until the user changes the default schedule.
Note: The Start/Stop button must be pressed, and the Start/Stop LED illuminated, for the pump to run.
