31
PME-MP55DP
HBMA0582-3.1 de/en/fr
The targeted operation of the required control bits in the control word allows
you to secure all the functions not required against accidental operation in the
event of an error; otherwise, for example, the zero point set could be lost.
If you are using older parameter assignment tools the parameter values will
have to be converted to decimal or hexadecimal values:
Octet Bits Parameter name Available values Default Meaning
0 0−7 reserved 0 0 do not change
1)
1−2 all Diagnosis 0 = locked
0xffff = released
released operation of external
diagnosis
3 all Data format 0 = integer 16 bits
1 = integer 32 bits
2 = floating point
integer 16 bits defines the coding
format for measured
values
4 0−1 Parameter set
control bits
0 = locked
3 = released
locked operates function for
control of output
control word
5 0 Zeroing control
bit
0 = locked
1 = released
locked operates function for
control of output
control word
5 1 Taring control bit 0 = locked
1 = released
locked operates function for
control of output
control word
5 4 Control bit
Clear maximum
0 = locked
1 = released
locked operates function for
control of output
control word
5 5 Control bit
Clear minimum
0 = locked
1 = released
locked operates function for
control of output
control word
5 6 Control bit
Hold maximum
0 = locked
1 = released
locked operates function for
control of output
control word
5 7 Control bit
Hold minimum
0 = locked
1 = released
locked operates function for
control of output
control word
Tab 6.2: Contents of the parameter assignment telegram
1)
changed by your parameter assignment tool in certain circumstances
